ST9402112A product summary
SEAGATE 40GB 2.5"" 4200RPM IDE HDD
- Manufacturer
- Seagate
- Interface Group
- PATA (IDE, UDMA, EIDE)
- Interface
- IDE
- Physical Size
- 2.5in
- Capacity
- 40GB
- Speed
- 4,200RPM
Seagate ST9402112A 40GB PATA (IDE, UDMA, EIDE) Hard Disk Drives
Part Specific Options
This part has the following options to purchase.
- 9AH417-502
- Refurbished
- 1 in stock
- Refurbished
- Call for stock
- 9AH417-188
- Refurbished
- Call for stock
- 9AH417-196
- Refurbished
- Call for stock
- 9AH417-504
- Refurbished
- Call for stock
ST9402112A product details
Seagate Momentus 40GB 2.5" Ultra ATA/100 2.5" Ultra-ATA/100
Momentus 4200.2 from Seagate is ideal for notebook applications that only require 4200-RPM and offers the perfect combination of performance and value. And for whisper-quiet load/unload acoustics and maximum shock tolerance, Momentus 4200.2 features the Seagate exclusive QuietStep ramp load technology. Distinctions - Low power consumption for maximum battery life - Whisper-quiet load/unload acoustics - Operating shock of 250 Gs to withstand rugged notebook environment
Features
- Average latency
- 5.6 ms
- Bytes per sector
- 512
- Component for
- Notebook
- HDD capacity
- 40 GB
- HDD number of cylinders
- 16383
- HDD number of heads
- 2
- HDD size
- 2.5"
- HDD speed
- 4200 RPM
- Interface
- Ultra-ATA/100
- Read seek time
- 12.5 ms
- Storage drive buffer size
- 8 MB
- Type
- HDD
- Write seek time
- 14.5 ms
Operational conditions
- Non-operating altitude
- -60.96 - 12192 m
- Operating altitude
- -60.96 - 3048 m
- Operating relative humidity (H-H)
- 5 - 90%
- Operating temperature (T-T)
- 5 - 55 °C
- Storage relative humidity (H-H)
- 5 - 95%
- Storage temperature (T-T)
- -40 - 70 °C
Power
- Operating voltage
- 5 V
- Power consumption (idle)
- 0.8 W
- Power consumption (read)
- 1.8 W
- Power consumption (standby)
- 0.26 W
- Power consumption (write)
- 1.8 W
- Start-up current
- 1 A
Weight & dimensions
- Depth
- 100.2 mm
- Height
- 9.5 mm
- Weight
- 100 g
- Width
- 69.8 mm
